20′ Hardtop Cargo Container / 8′ 6″ High

Interior Dimensions (L x W x H): 5.895 x 2.350 x 2.384 (Middle) / 2.309 (Side) mm

19′ 4¹/₈″ * 7′ 8½″ * 7′ 9⁷/₈″ (Middle) / 7′ 6⁷/₈″ (Side)

Maximum Gross Weight: 32.500 kg / 71.650 lbs

Container Tare Weight: 2.850 kg / 6.283 lbs

Maximum Payload: 29.650 kg / 65.367 lbs

Capacity: 32,10 m³ / 1.134 ft³

40′ Hardtop Cargo Container / 8′ 6″ High

Interior Dimensions (L x W x H): 12.020 x 2.342 x 2.388 (Middle) / 2.313 (Side) mm

39′ 5¼″ * 7′ 8¹/₈″ * 7′ 10″ (Middle) / 7′ 7″ (Side)

Maximum Gross Weight: 30.480 kg / 67.197 lbs

Container Tare Weight: 4.700 kg / 10.362 lbs

Maximum Payload: 25.780 kg / 56.835 lbs

Capacity: 67,20 m³ / 2.373 ft³

40′ HC Hardtop Cargo Container / 9′ 6″ High

Interior Dimensions (L x W x H): 12.032 x 2.352 x 2.695 (Middle) / 2.620 (Side) mm

39′ 5⁵/₈″ * 7′ 8⁵/₈″ * 8′ 10″ (Middle) / 8′ 7″ (Side)

Maximum Gross Weight: 32.500 kg / 71.650 lbs

Container Tare Weight: 5.200 kg / 11.464 lbs

Maximum Payload: 27.300 kg / 60.186 lbs

Capacity: 76,3 m³ / 2.695 ft³

20′ Open Top Container / 8′ 6″ High

Interior Dimensions (L x W x H): 5.895 x 2.350 x 2.380 (Middle) / 2.340 (Side) mm

19′ 4¹/₈″ * 7′ 8½″ * 7′ 9⁵/₈″ (Middle) / 7′ 8¹/₈″ (Side)

Maximum Gross Weight: 32.500 kg / 71.650 lbs

Container Tare Weight: 2.450 kg / 5.402 lbs

Maximum Payload: 30.050 kg / 66.248 lbs

Capacity: 32,5 m³ / 1.148 ft³

40′ Open Top Container / 8′ 6″ High

Interior Dimensions (L x W x H): 12.030 x 2.350 x 2.377 (Middle) / 2.347 (Side) mm

39′ 4¹/₈″ * 7′ 8½″ * 7′ 9⁵/₈″ (Middle) / 7′ 8¹/₈″ (Side)

Maximum Gross Weight: 30.480 kg / 67.196 lbs

Container Tare Weight: 3.850 kg / 8.488 lbs

Maximum Payload: 26.630 kg / 58.708 lbs

Capacity: 66,4 m³ / 2.345 ft³

40′ High Open Top Container / 9′ 6″ High

Interior Dimensions (L x W x H): 12.029 x 2.352 x 2.683 (Middle) / 2.649 (Side) mm

39′ 5½″ * 7′ 8½″ * 7′ 9⁵/₈″ (Middle) / 7′ 7¼″ (Side)

Maximum Gross Weight: 32.500 kg / 71.650 lbs

Container Tare Weight: 4.250 kg / 9.370 lbs

Maximum Payload: 28.250 kg / 62.280 lbs

Capacity: 74,9 m³ / 2.645 ft³

20′ Flat Rack / 8′ 6″ High

Length between corner posts: 5.612 mm / 18′ 4 7/8″ ft

Width between corner posts: 2.227 mm / 7′ 3 5/8″ ft

Floor/Underside rail width: 2.210 mm / 7′ 3″ ft

Interior height (floor to top): 2.219 mm / 7′ 3 3/8″ ft

Base height: 370 mm / 1′ 2 ½” ft

Maximum Weight: 34.000 kg / 74.957 lbs

Tare Weight: 2.740 kg / 6.041 lbs

Maximum Payload: 31.260 kg / 68.916 lbs

40′ Flat Rack / 9′ 6″ High

Length between corner posts: 11.652 mm / 38′ 2 3/4″ ft

Width between corner posts: 2.224 mm / 7′ 3 1/2″ ft

Floor/Underside rail width: 2.368 mm / 7′ 9 ¼” ft

Interior height (floor to top): 2.248 mm / 7′ 4 1/2″ ft

Base height: 648 mm / 2′ 1½” ft

Maximum Weight: 50.000 kg / 110.230 lbs

Tare Weight: 5.950 kg / 13.117 lbs

Maximum Payload: 44.050 kg / 97.113 lbs

20′ Flat/Platform with flat folding end wall and softwood floor
Interior dimensions (L x W x H): 6.058 x 2.438 x 370 mm

20′ * 8’ * 1′ 2½” ft

Maximum Weight: 34.000 kg / 74.957 lbs

Tare Weight: 2.740 kg / 6.041 lbs

Maximum Payload: 31.260 kg / 68.916 lbs

40′ Flat/Platform with flat folding end wall and softwood floor
Interior dimensions (L x W x H): 12.192 x 2.245 x 648 mm

40’ * 7′ 4 3/8″ * 1′ 2½” ft

Maximum Weight: 50.000 kg / 110.230 lbs

Tare Weight: 5.950 kg / 13.117 lbs

Maximum Payload: 44.050 kg / 97.113 lbs

20′ Refrigerated Container

Interior dimensions (L x W x H): 5.450 x 2.284 x 2.267 mm (17′ 10½” * 7′ 57/8″ * 7′ 5¼” ft)

Maximum stacking height (to loading beam): 2.184 mm / 7′ 2″ ft

Door dimensions (W x H): 2.290 x 2.264 mm (7′ 61/8″ * 7′ 51/8″ ft)

Maximum Gross Weight: 30.480 kg / 67.196 lbs

Container Tare Weight: 2.905 kg / 6.404 lbs

Maximum Payload: 27.575 kg / 60.792 lbs

Capacity: 28,2 m³ / 996 ft³

20′ Refrigerated Container (Non-food)

Interior dimensions (L x W x H): 5.535 x 2.316 x 2.331 mm (18′ 11/7″ * 7′ 71/8″ * 7′ 71/8″ ft)

Maximum stacking height (to loading beam): 2.211 mm / 7′ 3″ ft

Door dimensions (W x H): 2.316 x 2.290 mm (7′ 71/8″ * 7′ 6 1/8″ ft)

Maximum Gross Weight: 30.480 kg / 67.196 lbs

Container Tare Weight: 3.030 kg / 6.680 lbs

Maximum Payload: 27.580 kg / 60.803 lbs

Capacity: 28,7 m³ / 1.014 ft³

40′ Refrigerated Container

Interior dimensions (L x W x H): 11.578 x 2.280 x 2.525 mm (37′ 11¾” * 7′ 5¾” * 8′ 33/8″ ft)

Maximum stacking height (to loading beam): 2.425 mm / 7′ 11½” ft

Door dimensions (W x H): 2.276 x 2.535 mm (7′ 55/8″ * 8′ 3¾″ ft)

Maximum Gross Weight: 34.000 kg / 74.957 lbs

Container Tare Weight: 4.300 kg / 9.480 lbs

Maximum Payload: 29.700 kg / 65.477 lbs

Capacity: 66,7 m³ / 2.356 ft³

40′ Refrigerated Container

Interior dimensions (L x W x H): 11.578 x 2.280 x 2.525 mm (37′ 11¾” * 7′ 5¾” * 8′ 33/8″ ft)

Maximum stacking height (to loading beam): 2.425 mm / 7′ 11½” ft

Door dimensions (W x H): 2.276 x 2.535 mm (7′ 55/8″ * 8′ 3¾″ ft)

Maximum Gross Weight: 34.000 kg / 74.957 lbs

Container Tare Weight: 4.300 kg / 9.480 lbs

Maximum Payload: 29.700 kg / 65.477 lbs

Capacity: 66,7 m³ / 2.356 ft³

40′ Container with Atmospheric Control Technology (Extra Fresh)

Interior dimensions (L x W x H): 11.590 x 2.290 x 2.540 mm (38′ ¼” * 7′ 61/8″ * 8′ 4″ ft)

Maximum stacking height (to loading beam): 2.420 mm / 7′ 11¼″ ft

Door dimensions (W x H): 2.276 x 2.535 mm (7′ 55/8″ * 8′ 3¾″ ft)

Maximum Gross Weight: 34.000 kg / 74.956 lbs

Container Tare Weight: 4.570 kg / 10.075 lbs

Maximum Payload: 29.200 kg / 64.374 lbs

Capacity: 67,4 m³ / 2.380 ft³

40′ Refrigerated Container (Non-food)

Interior dimensions (L x W x H): 11.580 x 2.290 x 2.543 mm (37’11 7/8″ * 7′ 6 1/8″ * 8′ 4 1/8″ ft)

Maximum stacking height (to loading beam): 2.423 mm / 7′ 11 3/8″ ft

Door dimensions (W x H): 2.294 x 2.550 mm (7′ 5 5/8″ * 8′ 3 ¾″ ft)

Maximum Gross Weight: 34.000 kg / 74.957 lbs

Container Tare Weight: 4.550 kg / 10.031 lbs

Maximum Payload: 29.450 kg / 64.925 lbs

Capacity: 67,4 m³ / 2.380 ft³
